Product Overview:
🔍 The ZK-PP2K Signal Generator module is a highly versatile tool designed for generating Pulse Width Modulation (PWM) signals, offering precise control over frequency and duty cycle settings. It's perfect for a variety of applications, ranging from LED brightness adjustments to motor speed control and solenoid operation. This module features a clear LCD display, allowing users to easily monitor and adjust settings in real time.
🔧 Key Features:
- Direct Load Drive: Capable of directly driving loads such as LEDs, motors, and solenoid valves with ease.
- Dual Operating Modes:
- PWM Mode: Continuous frequency and adjustable duty cycle.
- PULSE Mode: Adjustable positive and negative pulse width, power-on delay start, and configurable switch frequency.
- User-Friendly Interface: Equipped with start and stop buttons for straightforward control of signal output.
- Wide Voltage Input: Operates from 3.3V to 30V, making it suitable for various applications.
🔘 Technical Specifications:
- Input Voltage: 3.3 to 30V (ensure correct polarity to prevent damage).
- Frequency Range: 1Hz to 150KHz with an accuracy of approximately 2%.
- Duty Cycle Range: 0-100% adjustable in 1% increments.
- Pulse Count: Configurable from 1 to 9999 pulses, or set to infinite (displayed as ‘----’).
- Delay Output: Adjustable from 0.000s to 9999s, with the minimum adjustment of 1ms.
- Pulse Width: Positive and negative pulse widths adjustable from 0.000s to 9999s.
- Output Capacity: Supports loads up to 8A via a MOS switch.
- Output Amplitude: Matches the supply voltage (internally connected OUT+ and V+).
- Dimensions: 79mm x 43mm x 30mm.
- Weight: 42g.
- Packaging: Comes in an anti-static bag for safe storage and transport.
🧩 Operational Mode Descriptions:
PWM Mode:
- Set frequency and duty cycle using dedicated buttons.
- Default settings upon power up are 1KHz frequency and 50% duty cycle.
🔘 PULSE Mode:
- Allows for detailed control over pulse parameters such as pulse width and delay time.
- Default values are set to 0.5 seconds for both positive and negative pulse widths.
- Users can define the total number of output pulses and delays before activation.
🧰 Applications:
- LED Control: Adjust brightness levels using PWM settings for smooth operation.
- Motor Control: Regulate motor speeds conveniently through precise frequency and duty cycle alterations.
- Solenoid Actuation: Effectively automate solenoid responses with adjustable cycle times and delays.
- Testing and Prototyping: Ideal for conducting reliability tests on equipment, including switching fatigue tests and voltage drop assessments.
💥 This extensive range of functionalities makes the ZK-PP2K Signal Generator an invaluable tool for hobbyists, engineers, and anyone needing precise control over electronic signals.
