Product Overview:
🪶 This high-quality LAN cable is specifically designed for use with CCTV IP camera board modules, providing an efficient and reliable connection for both data transmission and power supply. Ideal for security applications, this versatile cable allows for optimal setup within your surveillance system using Power over Ethernet (PoE) Mid-Span technology.
🔧 Features:
- 4-Pin LAN Connections: The cable includes four dedicated wires (green, green-white, blue, blue-white) for LAN/network connectivity, which correspond to pins 1, 2, 3, and 6 of the RJ45 connector, ensuring robust data transfer.
- Status LED Connection: A dedicated 1-pin (purple) wire is provided for connecting a status LED, allowing for easy monitoring of the camera's operational status while sharing a common ground.
- Power Supply Connections: Two additional wires (red and black) enable direct power supply from a DC jack for the camera's operation. This setup promotes efficient power delivery without degradation in performance.
- IR LED Power Supply: Another set of two wires (red and black) with a larger connector is included, specifically designed for powering infrared (IR) LEDs, enhancing nighttime surveillance capabilities.
- Additional POE Inputs: The cable features two extra wires (white and yellow) intended for POE Mid-Span type inputs, allowing for seamless power delivery over the LAN connections while eliminating the need for separate power lines.
⚡ Important Considerations:
- The DC jack is exclusively designed for input voltages of DC 12V. Exceeding this voltage may lead to damage of the status LED or the camera itself, compromising the integrity of your surveillance setup.
- It is essential to note that the DC jack is not equipped with a water-proof connector. Proper precautions, such as effective isolation during installation, should be taken to protect against water exposure.
📷 Packing List:
- 1 piece of LAN cable with connectors
